High Power Aluminum Waterproof IP66 Outdoor 60w 90w 120w Led Street Light
Construction and Materials
Housing: The housing is constructed out of high strength, lightweight bulk molding compound for long weathering and durability. UV stabilized polymeric door with handle pocket for toolless entry. Comes standard with Utility Label per ANSI C136.15 and 7-pin NEMA® Photocell Receptacle per ANSI C136.41
Wiring: Straight in wiring to terminal block for power input (#6-#14 AWG)
Optic Box: IP66 rated optic box and driver enclosure inside optic box
Luminaire: Luminaire secured with two mounting bolts
Mounting: Mounts on 1.25 inch IP, 1.66 inch O.D. or 2 inch IP, 2.375 inch O.D. horizontal tenon (minimum 8 inches in length) and is adjustable +/- 5˚ in 2.5˚increments to allow for fixture leveling (two axis T-level included)
Weight: 8.45 lbs.
Regulatory and Voluntary Qualifications
cULus: Listed suitable for wet locations
ANSI: Certified to ANSI C136.31-2001, 3G bridge and overpass vibration standards
CALTrans: Meets CALTrans 611 vibration testing
IEEE/ANSI: 10 kilovolt surge suppression protection tested in accordance with IEEE/ANSI C62.41.2
FCC: Meets FCC Part 15, Subpart B, Class A standards for conducted and radiated emissions
RoHS: RoHS compliant. Consult factory for additional details
IDA: Dark sky friendly, IDA Approved when ordered with 30K
Product Description
Product Code |
BTLED-1804 |
Material |
Diecasting aluminum |
Wattage |
A: 150W-240W
B: 100W-150W C: 40W-90W D: 20W-60W |
LED chip brand |
LUMILEDS/CREE/Bridgelux |
Driver Brand |
MW、PHILIPS、INVENTRONICS、MOSO |
Power Factor |
>0.95 |
Voltage Range |
90V-305V |
Surge Protection |
10KV/20KV |
Working temprature |
-40~60℃ |
IP rating |
IP66 |
IK rating |
≥IK08 |
Insulation Class |
Class I / II |
CCT |
3000-6500K |
Lifetime |
50000 hours |
Photocell base |
with |
Installation Spigot |
60/50mm |
